Matrox Extio 3 Series – User Guide 91
Extio 3 transmitter unit
Extio N3408 transmitter unit Extio N3208 transmitter unit
Product type
Standalone appliance Standalone appliance
Form factor 1 RU, half width 1 RU, half width
Video input connectors
4× DisplayPort
(with stereo L-PCM audio)
2× DisplayPort
(with stereo L-PCM audio)
Video output connectors
1× DisplayPort
(for local console)
1× DisplayPort
(for local console)
Audio input connector (analog) 1× mini-stereo jack 1× mini-stereo jack
Audio output connector 1× mini-stereo jack 1× mini-stereo jack
RS232 connector 1× DE9 (or DB9) – Female 1× DE9 (or DB9) – Female
Networking interface 1000 Base-T Ethernet 1000 Base-T Ethernet
SFP cage 
RJ45 copper transceiver 
SFP fiber module Optional Optional
USB ports
2× USB 2.0 (front)
*
,
1× USB 2.0 (back)
* For more information, see the Local console section in your Matrox Extio Central Manager User Guide.
2× USB 2.0 (front)
*
,
1× USB 2.0 (back)
DisplayPort version 1.1 
DisplayPort version 1.2 
†
† DisplayPort version 1.2 is supported on connector labeled 4 only.
—
Color space
YUV 4:4:4
RGB 8:8:8
YUV 4:4:4
RGB 8:8:8
Maximum input resolution
‡
‡ Additional display resolutions may be available. For more information, contact your Matrox representative.
4× 1920 × 1080 @60 Hz,
3× 1920 × 1200 @60 Hz,
2× 2560 × 1600 @60 Hz,
2× 3840 × 2160 @30 Hz,
1× 3840 × 2160 @60 Hz
2× 1920 × 1200 @60 Hz,
1× 2560 × 1600 @60 Hz
Power connector DIN 4-pin female DIN 4-pin female
Power consumption 57W (typical 44W) 34W (typical 25W)
Laser emissions
§
§ Only when using a multi-mode SFP module.
850 µm laser compliant to 21CFR, Subpart J, Class 1
Regulatory compliance
Class A: CE, FCC, ICES-3, KC, RCM, VCCI
CSA
