78 Matrox Extio 3 Series – User Guide
Switching to a different connection source
1
Under
Sources
, select the transmitter or aggregated layout ( ) you want to switch to.
2
Click
Connect
.
Transmitter status
View the status information (
Name
,
Guest connections
,
Name of user connected
, and
Keyboard
shortcut
) of the selected transmitter.
Inputs
View the connection information of the devices (
Monitor
,
Microphone
, and
Line In
) connected to the
selected transmitter.
Details
Provides information (such as the model, serial number, firmware package version, and the
minimum, current, and maximum internal temperature) on your Extio 3 device and
the connection
status and IP address of the device (connected through
LAN1
or
LAN2
).
Note:
You can also use the assigned keyboard shortcut that displays in the
Sources
list to
switch to the transmitter or aggregated layout.
