CONTROL SYSTEM
01–40–19
01–40
FUEL INJECTION CONTROL BLOCK DIAGRAM [LF]
E5U014000000N26
End Of Sie
IAT SENSOR
MAF SENSOR
MAP SENSOR
CMP SENSOR
ECT SENSOR
CKP SENSOR
BARO SENSOR
NEUTRAL SWITCH (MT)
CPP SWITCH (MT)
BRAKE SWITCH
NO.1, NO.2
A/C AMPLIFIER
REFRIGERANT PRESSURE
SWITCH (MIDDLE)
REFRIGERANT PRESSURE
SWITCH (LOW, HIGH)
BATTERY
VEHICLE SPEED
SIGNAL
TR SWITCH (AT)
SYNCHRONIZED
FUEL INJECTION
EFFECTIVE
INJECTION TIME
INJECTION
TIME AT
ENGINE START
BASIC
INJECTION TIME
VARIOUS
CORRECTION
TYPES
INEFFECTIVE
INJECTION TIME
NON-SYNCHRONIZED
INJECTION CONTROL
INEFFECTIVE
INJECTION TIME
FUEL INJECTOR ENERGIZATION
TIMING AND ENERGIZATION
TIME
FUEL INJECTOR
PCM
FRONT HO2S
TP SENSOR NO.1, NO.2
APP SENSOR NO.1, NO.2
REAR HO2S
E5U140ZT5003
