9.6 - HYDRAULIC SYSTEM MAINTENANCE
9.6.1 - HYDRAULIC OIL LEVEL CHECK
Check the hydraulic oil level every 8 working hours or daily.
• Do not top up oil beyond the MAX level, this could cause oil to leak from the
tank.
• Restore the level only using the hydraulic oil shown in the table (see 9.4.1).
• When using biodegradable oil Panolin HLP Synth E, avoid mixing it with other
oils.
• The use of non-recommended lubricants and/or greases will result in
invalidity of the warranty.
When topping up, wear protective clothing.
The hydraulic oil check must be done on the flat.
The hydraulic oil level is correct when it reaches the mark on the dipstick attached to the filler cap.
To check the oil level:
1. Unscrew the cap (A) and check the oil level on it.
2. If the level of oil is low, top it up until it reaches the mark.
3. Close the cap tightly.
Level OK
