3. ENGINE WARNING:
• Appears when errors in the diesel engine are detected. Contact McConnel’s support service;
• Flashes when stationary regeneration is required;
• Flashes when the DPF (level 1) has to be cleaned of ash. Contact McConnel’s support service;
4. STOP ENGINE:
• Appears when serious engine faults are detected. Stop the engine immediately and contact
McConnel’s support service;
• Flashes when the DPF (level 2) has to be cleaned of ash. Contact McConnel’s support service;
5. DPF REGENERATION CONSENT:
• Flashes during stand-by before regeneration and remains on when the stationary regeneration
starts.
• The indicator disappears when the regeneration ends;
6. DPF REGENERATION INHIBITED:
• Appears when the inhibit regeneration button is pressed.
6.4.8 - FUSES AND RELAYS
Before replacing a fuse, make sure that you have removed the ignition key. If the
fuses are oxidised, corroded or are not perfectly retained in place, only replace
with fuses of the same capacity. If the engine does not turn when the starter
switch is moved to the ignition position, check the main fuse and replace it if
necessary.
6.4.9 - FUSES AND RELAYS OF THE CENTRAL CONTROL UNIT
The fuses and the relays are situated in fuse box (A) on the right-hand side of the machine in the rear
engine compartment; remove the lid and change the fuses and relays if necessary.
