7.1.3 - ELECTRICAL CIRCUIT
Malfunction
Cause
Solution
The lights are not properly lit even when the
engine is running at a high speed.
Faulty cables.
Check and repair the defective terminals and
cables.(*)
Lights are not steadily lit while the engine is
running.
Defective fan belt tensioning.
Adjust belt tensioning.
The alternator charge indicator light does
not turn off when the engine is running and
accelerated.
Faulty alternator.
Replace.(*)
Faulty cables.
Replace.
The starter does not run when the key is
turned to the ignition position.
Faulty cables.
Check and repair.(*)
Insufficient accumulator charge.
Charge the accumulator.
Faulty main fuse.
Replace.
The starter pinion is engaged and then
released.
Insufficient accumulator charge.
Charge the accumulator.
The starter makes the engine run slowly.
Insufficient accumulator charge
Charge the accumulator.
Faulty starter motor
Replace.(*)
The starter deactivates before the engine
starts.
Faulty cables
Check and repair.(*)
Insufficient accumulator charge.
Charge the accumulator.
The alternator charge indicator light does not
turn on when the engine is stopped (ignition
key on "I").
Faulty light
Replace.(*)
Faulty cables
Check and repair.(*)
(*) If the fault or the cause that caused it is not indicated in the tables below, contact McConnel for the necessary repair.
7.1.4 - HYDRAULIC SYSTEM
Malfunction
Cause
Solution
The pump makes a strange noise.
Faulty pump
Repair or replace.(*)
Lack of oil in the tank
Fill to level
The equipment moves at low speed.
Faulty pump
Repair or replace.(*)
Maximum pressure valve out of calibration or
not closed due to impurities
Adjust or replace.(*)
Dirty discharge filter
Replace the cartridge
(*) If the fault, or the cause that caused it, is not indicated in the tables below, contact McConnel for the necessary repair.
