6.3.7 - TRAVEL SPEED POTENTIOMETER
The potentiometer (12) regulates the maximum speed of the machine from 0 to 100%. The
potentiometer setting chosen will depend on the various work conditions that the operator
will come across and should always ensure maximum control over the machine.
6.3.8 - MOVING THE MACHINE FORWARDS AND BACKWARDS
The forward travel of the machine is controlled by the left-hand proportional joystick (A).
• The machine moves forwards by shifting the joystick (A1) forwards.
• It reverses when the joystick (A2) is shifted backwards.
• It is a proportional control so the more you move the joystick the faster the machine moves.
• The top speed that can be achieved will be determined by the potentiometer position (12)
and the speed selected (3).
