McConnel ROBOCUT2 RC40 - Page 38

29
McCONNEL
WEIGHT
The total weight of the RC40 machine, without equipment, is 1150 kg.
DRIVES
Supplier
YANMAR
Type
3TNV88C
DYI2D
No. of cylinders
3
Engine displacement
1642 cc
Power @ 3000 rpm
29 kW / 40 CV
Peak torque @ 1950 rpm
105 Nm
Cooling
Liquid
Air filter
Dry
Exhaust gas standard
USA
EPA Final Tier 4
EU
Stage V
ELECTRICAL SYSTEM
Operating voltage 12 VDC
Alternator 55 A
Battery 18 Ah
HYDRAULIC SYSTEM
Circuit
Pump type
Qty
Maximum capacity
L/min
Bar
Travel
Tandem variable displacement
piston pump in closed circuit
2
28.5 each
250
Cutting head
Variable displacement pistons
type in closed circuit
1
55
280
Services
Gear pump
1
12
190
TRAVEL SPEED
Forward
Reverse
Speed
1 (Slow)
2 (Fast)
1 (Slow)
2 (Fast)
Km/h
0 - 4
0 - 7
0 - 4
0 - 7
