3. Slowly move the RC40 until it is close to the mounting plate of the tool that was previously
placed in front of the machine;
4. Using the right-hand joystick (B), raise the lifting device to attach the equipment;
5. Secure the tool with six M12 x 40 bolts to the machine support using an 18-mm spanner;
6. Turn off the engine;
7. Connect the hydraulic power lines of the tool to the quick couplings on the right-hand side
of the machine; taking care to clean them before making the connection. The outermost
coupling is for the drainage line, while the inner two are for lines (A) and (B).
