7. Unscrew the oil filler cap (D);
8. Retighten the oil sump drain cap (C) once all the oil has drained out;
9. Remove the side guard (E);
10. Unscrew the filter cartridge (F) anticlockwise and remove it;
11. Apply a film of clean oil to the new filter in the external and internal seals, and the filter thread;
12. Dry the sealing head of the filter thoroughly with a clean rag and reinstall the filter, tightening it with
the wrench (max. torque 19.6 - 23.5 Nm);
13. Fill the sump with a suitable engine oil (see the lubricants and fluids table in section 9.4.1) and close
the filler cap (D).
14. Start the engine and leave it running for approximately five minutes at idle speed. Then, turn the
engine off and after approximately three minutes, check the oil level using the dipstick (G). Top up if
necessary.
15. Reassemble the guards (A) and (E).
