Table 112. Input/Output Signals − Voice Warning LRU (600N4514−3/−5)
Pin Description Function Voice message
A Input fron N1 sensor Detects frequency below 9817 HZ (ECU
manual mode)
Engine out
B Power input 23−30 Vdc (Bus) N/A
C Output Audio out, 100 Mw into 600 Ohms N/A
D Input Contact to ground Fuel flow fixed
E Input Power ground N/A
F Input Contact to bus from FADEC Engine out
G Audio in (−5 only) Audio from COMM N/A
H Input Case ground N/A
K Input Detects voltage above 2.98 Vdc Power
L Input from rotor sensor Detect frequency below 1321 HZ Low rotor
P Input Contact to bus Voise warning test
S Input Contact to bus Fire
T Input Contact to ground E.C.U. manual
U Output Bus voltage out to ignition exciter if in ECU
manual and low N1 or low rotor
N/A
NOTE: Pins J, M, N & R are not used −3 or −5.
Pin G not used on −3.
Table 113. Input/Output Signals − Voice Warning LRU (600N4515−1)
Pin Description Function Voice message
A Input fron N1 sensor Detects frequency below 9817 HZ (ECU
manual mode)
Engine out
B Power input 23−30 Vdc (Bus) N/A
C Output Audio out, 400 Mw into 75 Ohms N/A
D Input Contact to ground Fuel flow fixed
E Input Power ground N/A
F Input Contact to bus from FADEC Engine out
G Audio in ICS audio N/A
H Input Case ground N/A
J Output Audio 2, 400 Mw into 75 Ohms N/A
K Input Detects voltage above 2.98 Vdc Power
L Input from rotor sensor Detect frequency below 1321 HZ Low rotor
P Input Contact to bus Voise warning test
S Input Contact to bus Fire
T Input Contact to ground E.C.U. manual
U Output Bus voltage out to ignition exciter if in ECU
manual and low N1 or low rotor
N/A
NOTE: Pins M, N & R are not used.
