MD Helicopters 369D - Revision

CSP−HMI−3
MD Helicopters, Inc
.
MAINTENANCE MANUAL
[ Main Menu ]
[ HMI−3 Book TOC ]
95 Contents
Page ix
Revision 14
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
TABLE OF CONTENTS (Cont.)
Para/Figure/Table Title Page
B. Preparation for Installation 901..............................................
C. Helicopter Equipment Removal 901...........................................
D. Instrument Panel Support Structure Modification (Slim-Line Instrument Panel) ......
901
E. Angles Modification 901.....................................................
F. T-brackets and Support Assembly Installation 901.............................
G. Instrument Panel Modification (L/H Command T-Panel) 902...................
H. Instrument Panel Modification (R/H Command T-Panel) 902...................
I. Directional Gyro Indicator Installation (Slim-Line Instrument Panel) 902........
J. Directional Gyro Indicator Installation (L/H Command T-Panel) 902............
K. Directional Gyro Indicator Installation (R/H Command T-Panel) 903............
L. Completion of Installation 903................................................
M. Weight and Balance Data 903................................................
Table 901. Weight and Balance Data 903......................................
95-30-00 Power Train Instruments A.............................................
Description and Operation 1...................................................
1. Power Train Instruments Description and Operation 1.........................
2. Tachometer Indicating System (369D/E/FF - 500N) 1..........................
3. Digital N1 Tachometer Indicator (600N) 1.....................................
4. N2/NR Dual Tachometer Indicator (600N) 1...................................
5. NR/NP Dual Tachometer Indicator (600N) 1...................................
6. TOT Indicating System (369D/E/FF - 500N) 1.................................
7. Analog/Digital Torque Indicator (600N) 1......................................
8. Analog Indicator - Torque, TOT (600N) 2......................................
9. Quad Digital Indicator - Torque, TOT, OAT, N1 (600N) 2.......................
10. Oil Pressure Indicating System (369D/E/FF - 500N) 2..........................
11. Engine Oil Temperature - Oil Pressure Indicator (600N) 2......................
12. Quad Digital Indicator - Oil Temp, Oil Press, VDC, AMP (600N) 2...............
13. Engine Torque Indicating System (369D/E/FF - 500N) 2........................
14. Engine Out Warning System (369D/E/FF - 500N) 3............................
A. N1/NR Sensing Equipment 3...............................................
B. Engine Out Warning System Functioning 3.................................
15. Autronics EPO Warning Control Unit (369D/E/FF - 500N) 4....................
A. Slim-Line Instrument Panels 4............................................
B. R/H command T-Panels 4.................................................
C. L/H command T-Panels 4.................................................
