MD Helicopters 369D - Revision

CSP−HMI−3
MD Helicopters, Inc
.
MAINTENANCE MANUAL
[ Main Menu ]
[ HMI−3 Book TOC ]
Page viii
Revision 14
95 Contents
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
TABLE OF CONTENTS (Cont.)
Para/Figure/Table Title Page
C. Instrument Panel Modification (Slim-Line Instrument Panels) 901..............
D. Instrument Panel Modification (L/H Command T-Panels) 901...................
E. Instrument Panel Modification
(IVSI SLZ9066, R/H Command T-Panels) 901.................................
F. Instrument Panel Modification
(IVSI UI7130 or AC-30-V-10, R/H Command T-Panels) 901...................
G. IVSI Installation (369H90044-BSC, Slim-Line Instrument Panels) 901..........
H. IVSI Installation (369H90044-501, Slim-Line Instrument Panels) 902..........
I. IVSI and Bolt Light Installation (L/H Command T-Panels) 902.................
J. IVSI and Grimes Light Assembly Installation
(R/H Command T-Panels) 902................................................
K. Completion of Installation 903................................................
L. Weight and Balance Data 903................................................
Table 901. Weight and Balance Data 904......................................
95-20-00 Magnetic Compass A....................................................
Maintenance Practices 201.......................................................
1. Magnetic Compass 201.........................................................
2. Magnetic Compass Troubleshooting 201.........................................
Table 201. Troubleshooting Magnetic Compass 201.............................
A. Magnetic Compass Maintenance Practices 201.................................
3. Magnetic Compass Ground Swinging 201........................................
Figure 201. Magnetic Compass (369D) 202....................................
Figure 202. Magnetic Compass (369E/FF - 500/600N) 203......................
95-20-10 Directional Gyro Indicators A..........................................
Maintenance Practices 201.......................................................
1. Directional Gyro Indicators 201.................................................
A. Directional Gyro Indicator Operating, Handling and
Shipping Guidelines 201.....................................................
B. Directional Gyro Indicator Troubleshooting 201................................
2. Directional Gyro Indicator Replacement 201.....................................
3. Directional Gyro Indicator Inspection 201.......................................
A. Directional Gyro Indicator Repairs 201........................................
Table 201. Troubleshooting Directional Gyro Indicator 201......................
Figure 201. Directional Gyro Indicators Wiring Diagrams and
Installation (Sheet 1 of 3) 202......................................
Initial Installation 901............................................................
1. Directional Gyro Indicator Initial Installation 901................................
A. Directional Gyro Indicator Operating, Handling and
Shipping Guidelines 901.....................................................
