EDGE LIGHTED
SWITCH PANEL
CIRCUIT BREAKER
PANEL
INSTRUMENT
PANEL CONSOLE
KEY SWITCH
(IGNITION)
INSTRUMENT PANEL (T-PANEL)
(NOTE 1)
CIRCUIT BREAKER PANEL
REAR VIEW
SWITCH PANEL
TOP VIEW
NOTES
:
1. NUMBER, SIZE (AMPS) AND FUNCTION OF CIRCUIT
BREAKERS VARIES BASED ON EQUIPMENT INSTALLED.
2. EFFECTIVE ON 600N, 001 AND SUBS.
6G96-083
Figure 207. Electrical Distribution Switches and Circuit Breakers,
600N Helicopters
