MD Helicopters 369D - Headset Cable Assemblies

CSP-HMI-3MD Helicopters, Inc.
MAINTENANCE MANUAL
[ Main Menu ]
[ HMI−3 Book TOC ]
[ Chapter 97 TOC ]
97-01-00
Page 7
Revision 12
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
G97-0103-1
M39029/22-192 (-5)
M39029/1-101 CONTACT (-BSC)
5 PLACES
RNF 100
SLEEVING
(WHITE)
U92A/U
CONNECTOR
WF-14/U CORD
423-059
423-059
423-059-3 423-059-3
J29A/U
423-059-BSC, -5
U94A/U (REF)
WHITE
M39029/22-192 CONTACT (FOR -7 & -9)
6 PLACES
M39029/1-101 CONTACT (FOR -3)
6 PLACES
RNF 100
SLEEVING
(WHITE)
U94A/U
SWITCH, JACK
WM-85/U CORD
423-059-3, -7 & -9
U94A/U
MIL-I-631
ÉÉ
ÉÉ
2 4 3 1
YELLOW
BLACK
SHIELD
RED
GREEN
Figure 3. Headset Cable Assemblies (Sheet 1 of 4)
