Table 202. Wire Identification
EXAMPLE: WIRE NUMBER 2P511A20N
2 P 511 A 20 N
UNIT NUMBER (IF USED)
CIRCUIT DESIGNATION
WIRE NUMBER
GROUND
WIRE SIZE
WIRE SEGMENT
Circuit Designation Circuit Function
A Armament Control
C Flight Control
D Ammeter and Miscellaneous
E Engine Instruments
F Flight Instruments
H Heating and Associated
J Engine Re-ignition
K Starting
L Lighting
M Utility
P DC Power Distribution
Q Fuel and Oil
RV *VHF Radio and Intercom
X AC Power Distribution
NOTE: Function indicated with an asterisk (*) pertains to avionics equipment. Other miscellaneous circuit designa-
tors are used for specific circuits of special equipment configurations and optional avionics and navigation
equipment.
