96-00-00
Page 219
Revision 11
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
TAIL POSITION
LIGHT
ANTI-COLLISION
LIGHT (STROBE)
E19
(NOTE 6)
ENGINE OUT
AUDIBLE WARNING
HORN (NOTE 7)
E502
(NOTE 8)
E16
(NOTE 6)
E7
E25
(NOTE 8)
ENGINE OUT
AUDIBLE
WARNING HORN
(NOTE 6)
TB7
J11
2
J100 APU
RECEPTACLE
APU RELAY
K309
E4
J109
TB5
J10
E1
369E; 384 & SUBS
369FF; 076 & SUBS
369E; 003 - 383
369FF; 001 - 075
J9
TB1
TB5
E1
E1
J1201
TB200
EPO
GC
U
P9
TB201
P110
J1202
BATTERY RELAY
K310
369E/369FF BATTERY
COMPARTMENT
G96-0005-4A
Figure 205. Component Location (Sheet 4 of 6)
