96-05-10
Page 203
Revision 8
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
G96-0011
BATTERY COMPARTMENT
ACCESS DOOR
RIVET
PIN
HINGE HALF
TB1 TERMINAL BOARD
SUPPORT BRACKET
DECAL
RIVET
BATTERY
SCREW
WASHER
SCREW
RIVET RIVET
NUTPLATE
RIVET
SUPPORT
ASSEMBLY
P108
CONTACT PIN
NUTPLATE
369A2515-66 SUPPORT
BRACKET
Figure 202. Battery Installation
