G96-0013A
0.12 IN.
(0.3048 MM)
2.50 IN. (6.35 CM)
SUPPORT ASSY
(NOTE 1)
STA. 60.40
CHANNEL
SUPPORT ASSY
(NOTE 2)
STA. 47.15
CHANNEL
NOTES:
1. INSTALL RIVETS WITH HEAD ON FWD SIDE.
2. INSTALL RIVETS WITH HEADS ON AFT SIDE.
Figure 902. Battery Support Installation
