Table 202. Optional Equipment Electrical Load Analysis Chart, 369D/E Helicopters (Cont.)
EQUIPMENT
OPTIONS
HOVER CRUISE
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
5 SEC 2 MIN
15
MIN
5 SEC 2 MIN
15
MIN
5 SEC 2 MIN
15
MIN
5 SEC 2 MIN
15
MIN
GYRO
ATTITUDE 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
DIRECTIONAL 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
SEARCHLIGHT
DUAL 33.9 33.9
QUAD 66.6 66.6
UTILITY FLOAT LANDING LIGHT 33.6 33.6
CARGO HOOK
HOIST 35.0 35.0 35.0 35.0 35.0 35.0
EMERGENCY FLOATS
SQUIB (13)
SOLENOID (13)
HEATED PITOT TUBE 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
AUTO RE-IGNITION
PARTICLE SEPARATOR 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
ANTI-ICE FUEL FILTER (13) 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0
INTERCOM, ICS CARTER 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2
SSB - SUNAIR, ASB/125/60 REC. 2.5 2.5 2.5 2.5 2.5 2.5 2.5 2.5
369H90144 TRANS. 7.5 7.5 7.5 7.5
PA - UNIVERSITY SOUND IDLE 0.1 0.1 0.1 0.1 0.1 0.1 0.1 0.1
369H90143 TRANS. AVG. 8.0 8.0 8.0 8.0
ADF RADIO KING KR85 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
KING KR86 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
COLLINS ADF650 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
TRANSPONDER KING KT-76 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3
COLLINS TDR950/950L 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4 1.4
NAV./COMM. KING COMM. RCVR. 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
KX-17CB/175B, KY-195/8 COMM. TRANS. 4.5 4.5 4.5 4.5
NAV. RCVR 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5 0.5
LAMPS 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2
COMM. TRANS. COMM. RCVR. 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
COLLINS VHF-251 COMM. TRANS. 5.1 5.1 5.1 5.1
COLLINS VIR-351 NAV. RCVR 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
INSTALLED OPTIONS AMPERES
BASIC SHIP AMPERES 29.3 21.7 13.3 51.2 43.6 18.7 13.3 13.3 13.3 18.6 18.6 18.6
TOTAL SHIP AMPERES
