Table 204. Optional Equipment Electrical Load Analysis Chart, 369FF Helicopters (Cont.)
EQUIPMENT
OPTIONS
HOVER CRUISE
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
5
SEC
2
MIN
15
MIN
5
SEC
2
MIN
15
MIN
5
SEC
2
MIN
15
MIN
5
SEC
2
MIN
15
MIN
GYRO
ATTITUDE 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
DIRECTIONAL 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8 0.8
SEARCHLIGHT, DUAL 33
UTILITY FLOAT LANDING LIGHT
CARGO HOOK
EMERGENCY FLOATS (SQUIB)
FLOATS, PRESS-TO-TEST
HEATED PITOT TUBE 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0 4.0
PARTICLE SEPARATOR 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6 0.6
COMM., KING (KX175/8) COMM. RCVR 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
COMM. TRANS. 3.0 3.0 3.0 3.0
ADF RADIO KING KR87 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75
COLLINS ADF650 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2
TRANSPONDER KING KT-75A 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
COLLINS TDR950 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75
COMM., KING (KX175/8) COMM. RCVR. 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
COMM. TRANS. 3.0 3.0 3.0 3.0
COMM., KING (KY196) REC. 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4 0.4
TRANS. 5.0 5.0 5.0 5.0
INTERCOM, ICS CARTER 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2 0.2
NAV. / COMM.. COLLINS DUAL
VHF-251 COMM. RCVR. 1.68 1.68 1.68 1.68 1.68 1.68 1.68 1.68
COMM. TRANS. 4.5 4.5 4.5 4.5
VIR-351 NAV. RCVR 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75 0.75
INSTALLED OPTIONS AMPERES
BASIC SHIP AMPERES 97.31 63.61 9.61 101.41 67.71 13.71 8.81 5.11 5.11 10.21 9.21 9.21
TOTAL SHIP AMPERES
