Table 207. Optional Equipment Electrical Load Analysis Chart, 600N Helicopters
EQUIPMENT
OPTIONS
NO.
OF
UNITS
OR
SYS.
AMPS
PER
UNIT
OR
SYS
OPER.
TIME
IN
MIN.
T
O
T
A
L
AMPS
PRE-START
START
TURBINE
TAKEOFF AND CLIMB
AVG. AMPS. AVG. AMPS.
DAY
AVG. AMPS.
NIGHT
AVG. AMPS.
5
SEC
2
MIN
5
SEC
2
MIN
5
SEC
2
MIN
5
SEC
2
MIN
GYRO
ATTITUDE 1 1.0 CON. 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
DIRECTIONAL 1 1.0 CON. 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0 1.0
CARGO HOOK 1 15.0 INTR. 15.0 15.0
FLOATS 1 5.0 INTR. 5.0
HEATED PITOT TUBE 1 5.0 CON. 5.0 5.0 5.0 5.0 5.0
ICS KMA24H 1 2.0 CON. 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
ADF KR87 1 3.0 CON. 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
NAV./COMM. KY155 1
3.0
2.0
INTR.
CON.
5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
COMM. KY196A 1
3.0
2.0
INTR.
CON.
5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0 5.0
COMM. KFM965 1 3.0 INTR. 3.0 16.5 16.5 16.5 16.5 16.5 16.5 16.5 16.5
GPS
KLN90A 1 3.0 CON. 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
GARMAN GPS150 1 3.0 CON. 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0 3.0
TRANSPONDER
KT70 1 1.5 CON. 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
KT76 1 1.5 CON. 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
RADAR ALTIMETER 1 1.0 CON. 1.0 1.0 1.0 1.0 1.0
ACTUATOR, YSAS SYS. 5.0 INTR. 5.0 5.0 5.0 5.0 5.0
INSTALLED OPTIONS - AMPERES
BASIC SHIP AMPERES 45.42 15.55 5.85 16.55 5.85 244.91 144.21 248.81 148.51
TOTAL SHIP AMPERES (NOTE)
NOTE: CONFIGURATION TOTALS SHOULD REFLECT INSTALLED OPTIONS ONLY.
