L. Weight and Balance Data
Weight and balance data resulting from
installation of searchlight kit is listed in
Table 901. After installation of kit, incorporate
changes in helicopter weight and balance
records as instructed in CSP HMI 2.
Table 902. Weight and Balance Data
Configuration Weight
Pounds (kg)
Arm
Inches (cm)
Moment
in−lb (kg cm)
−501 Assembly complete
Added 4.8 (2.177243) 115.6 (293.624) 5.55 (6.394266)
Removed 0.0 (0.0) 0.0 (0.0) 0.0 (0.0)
Changed +4.8 (+2.177243) 115.6 (293.624) −5.55 (−6.394266)
−501 Assembly (without 500−A searchlight assembly)
Added 6.3 (2.857632) 52.8 (134.112) 333 (383.65596)
Removed 4.3 (1.950447) 53.0 (134.62) 227 (261.53124)
Changed +2.0 (+0.9071847) 53.0 (134.62) 106 (122.12472)
