Page 904
Revision 12
97-02-00
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
G97-0205A
OUTBD
LOOKING FORWARD
WL 13.10
CARGO FLOOR
WL 15.85
369H2516 FRAME
CANT STA 78.50
0.875 IN. (22.225 MM) HOLE
369A2516-197 DOUBLER
MS20470AD3 RIVET (7 REQD)
RBL
19.06
0.140-0.152 IN.
(3.556-3.861 MM)
(4 HOLES)
0.406 IN.
(10.312 MM)
3.12 IN.
(7.925 CM)
J502
0.406 IN.
(10.312 MM)
8.12 IN. (20.625 CM)
Figure 902. Doubler Installation
