97-08-00
Page 203
Revision 12
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
G97-0801-1
MICROPHONE
SCREW
WASHER
HOLDER
(NOTE 1)
SCREW
(NOTE 2)
-17
-19
-15
GROMME
T
SUPPORT
NUT
WIRE HARNESS ASSEMBLIES
RIVET
NUTPLATE
WASHER
SCREW
CONTROL UNIT
CONTROL UNIT ATTACHMENT
INSTRUMENT PANEL
LOWER CIRCUIT BREAKER
AND SWITCH PANEL
CB129
NOTES:
1. MICROPHONE AND HOLDER ARE PROVIDED
AS A UNIT.
2. ATTACHMENT SCREWS ARE SUPPLIED
WITH CONTROL UNIT.
3. ATTACHMENT BOLTS ARE SUPPLIED WITH
AMPLIFIER.
4. EXISTING RIVET HOLES.
Figure 201. Public Address and Siren System (Sheet 1 of 2)
