95-00-20
Page 203
Revision 7
The information disclosed herein is proprietary to MD Helicopters, Inc.
Neither this document nor any part hereof may be reproduced or transferred to
other documents or used or disclosed to others for manufacturing or any other
purpose except as specifically authorized in writing by MD Helicopters, Inc.
Copyright © 1999−2016 by MD Helicopters, Inc.
ENGINE OUT AUDIBLE
WARNING HORN
CAUTION AND
WARNING LIGHTS
ALTIMETER
INDICATOR
ENGINE OIL TEMPERATURE
INDICATOR
ENGINE OIL PRESSURE
INDICATOR
TORQUE INDICATOR
AIRSPEED
INDICATOR
FUEL QUANTITY
INDICATOR
TURBINE OUTLET
TEMPERATURE
(TOT) INDICATOR
AMMETER
INDICATOR
ATTITUDE
INDICATOR
BOLT LIGHT
(10 PLACES)
CLOCK
TACHOMETER ENGINE
N2 & ROTOR INDICATOR
N1 TACH INDICATOR
DIRECTIONAL GYRO
INDICATOR
KEY SWITCH
INST. VERT. SPEED
INDICATOR
G95-0024
Figure 202. L/H Command T−Panel − Front View (Typical)
