User Manual for the Meca500 Industrial Robot (for rmware 10.1) 15
TECHNICAL SPECIFICATIONS
Table 5 lists the technical specifications for the power supply for both R3 and R4 revisions of the
Meca500. As already mentioned, the power supply provided has an IEC C14 connector that accepts an
AC power cord with three-prong IEC C13 connector on one end, and your own country's power plug on
the other. You can connect this power cord to any AC source that supplies voltage between 90 V and
250V at frequency between 50 Hz to 60 Hz. We also recommend that you use a surge protector, such as
the ASCO Model 241 from Schneider Electric.
We recommend that you use a surge protector when connecting the power supply to an AC
power source.
Table 6 and Table 7 list the requirements for the I/O connections on the power supply in the case of the
Meca500 R3 and R4, respectively. Further details will be provided in Section 7.
Finally, the CAD files of the Meca500 robot arm and of its power supply (in STEP format) can be
downloaded from our web site. You can also use one of several robot simulation and offline
programming software packages that include a model of our Meca500, including Visual Components and
RoboDK. Note that we also offer a Mecademic-only version of RoboDK, for exclusive use with our robots.
