Page 9 - 26 TA3H, TA3SH & TA3.5SH
9. Maintenance
1. Axle Fill Plug
2. Axle Level Plug
3. Axle Drain Plug
4. Transfer Box Level/Fill Plug
5. Transfer Box Drain Plug
(1) To Check the Oil Level in the Axle
(2) To Change the Oil in the Axle
(3) To Check the Oil Level in the Transfer Box
PROCEDURE
1. Park the machine on firm, level ground.
2. Clean the dirt from around the plugs.
3. Remove the oil level plug - 2.
4. The oil should be level with the bottom of the hole.
5. To add oil, remove the filler plug - 1.
6. Add the correct grade of oil through the filler plug until it begins to discharge from the level
hole.
7. Re fit and tighten the level and filler plugs.
PROCEDURE
1. Park the machine on firm, level ground.
2. Clean the dirt from around the plugs.
3. Place a suitable container under the drain plug - 3.
4. Remove the filler plug - 1 and drain plug - 3 and permit the oil to drain.
5. When oil has fully drained clean and refit the drain plug.
6. Remove the level plug.
7. Add the correct grade of oil through the filler hole until it begins to discharge from the level
hole.
8. Re fit and tighten the level and filler plugs.
PROCEDURE
1. Make sure the oil is warm not hot.
2. Park the machine on firm level ground, stop the engine and remove the start key.
3. Clean any dirt from around the level/fill plug - 4
4. Remove the plug -the oil should be level with the level/fill plug hole.
5. If necessary add oil of the correct specification until it just starts to flow from the hole.
6. Refit the plug and tighten.
7. Clean up any spilt oil.
