Page 7 - 2 TA3H, TA3SH & TA3.5SH
7. Standard Operating Procedures
2 Locking Pin
7.3 To Lower the ROPS for Transport
7.4 Seat
The seat is adjustable for operator comfort. The adjustments allow the seat to be moved forwards
and backwards, the back of the seat may be tipped forwards and backwards and the seat
suspension may be adjusted to the weight of the operator.
Figure 7.2. - Operators Seat
1. Fore and aft movement
2. Backrest Angle Adjustment
3. Weight Adjustment
PROCEDURE
1. Remove the linch pins from the locking pins.
2. Remove the locking pins.
3. Push the top section of the ROPS upwards to its working position.
4. Refit the locking pins and secure with the linch pins.
5. Fit the beacon.
PROCEDURE
1. Remove the beacon.
2. Remove the linch pins from the locking pins.
3. Remove the locking pins.
4. Lower the top section of the ROPS downwards.
5. Refit the locking pins and secure with the linch pins.
