TA3H, TA3SH & TA3.5SH Page 3 - 3
3. Technical Data
3.2 Turning Circle
Figure 3.3 - Turning Circle
Table 3.3 - Turning Circle
Turning Circle A mm (in)
TA3H TA3SH TA3.5SH
Ø 9421 (370.0) Ø 9105 (358.4) Ø 9105 (358.4)
A
COV0000
7
