TA3H, TA3SH & TA3.5SH Page 3 - 5
3. Technical Data
Table 3.4 Data (continued
3.4 Noise Emmissions
Table 3.5 - Noise Emissions
Note: The noise figures are only applicable for European CE Markets only.
3.5 Vibration Levels
Table 3.6 - Hand/Arm Vibration
Note: these values are for guidance only. Actual work site, operation and operator characteristics
will have a large influence on actual values for specific circumstances.
TA3H TA3SH TA3.5SH
Machine Weights
Unladen- Kg (tons) 2320 (2.55) 2380 (2.62) 2380 (2.62)
Operating Mass - Kg (Tons) 2395 (2.64) 2455 (2.70) 2455 (2.70)
Laden - Kg (Tons) 5395 (5.94) 5455 (6.01) 5955 (6.56)
Front Axle Laden - Kg (Tons) 3073 (3.38) 3651 (4.02) 4124 (4.54)
Rear Axle Laden - Kg (Tons) 2322 (2.55) 1804 (1.98) 1831 (2.01)
Skip Capacity
Maximum Safe Payload 3000kg (6600lb) 3000kg (6600lb) 3500kg (7716lb
Heaped Capacity 1.95 cu M (2.5 cu yds) 1.87 cu M (2.4 cu yds) 1.87 cu M (2.4 cu yds)
Water Capacity 1.25 cu M (1.6 cu yds) 1.00 cu M (1.3 cu yds) 1.00 cu M (1.3 cu yds)
Struck Capacity 1.60 cu M (2.0 cu yds) 1.50 cu M (1.9 cu yds) 1.50 cu M (1.9 cu yds)
Operating Environment
This machine can operate in ambient temperatures of between -15°C and +46°C without special
preparation. Refer to fluids and lubricants
Model
Declared Single-Number Noise Emission
Values to ISO 4871
A- rated sound pressure level at
operator station
A - rated sound power of machine
LpAd LWAd
TA3H 84dB 101dB
TA3SH 84dB 101dB
TA3.5SH 84dB 101dB
Operation Value Uncertainty
Hand Arm Vibration
as
defined in EN474-1
All operations <2.5m/s2 N/A
Whole body vibration
values as defined in
ISO/TR 25398
Work Cycle 0.529 rms 0.264m/s2
