Page 4 - 6 TA3H, TA3SH & TA3.5SH
4. Description
Figure 4.4 - Hydraulic System - Forward Tip
1. Ram - Skip Tip
2. Skip Control Valve
3. Hydraulic Pump - Steering and Skip Functions
4. Oil Cooler
5. Engine
6. Hydraulic Pump - Transmission
7. Hydraulic Motor - Transmission
8. Hydraulic Tank
9. Return Filter
10. Ram - Steering
11. “Orbitrol” Steering Unit
COV00025
1
2
3
4
5
67
8
9
10
11
