TA3H, TA3SH & TA3.5SH Page 8 - 3
8. Emergency Operating Procedures
Figure 8.2. - Setting the Pump to “Freewheel”
1. Adjusting Screws.
2. Lock Nuts.
3. Pump.
1 To Set the Pump to Freewheel.
It is necessary to remove the floor plate to gain access to the pump - see Battery Access in
Maintenance section.
2 To Reset the Pump
NOTICE
Failure to place the machine in “Freewheel” mode before towing will cause serious damage to
the pump, motor and hydraulic system.
PROCEDURE
1. Slacken the lock nuts each side of the pump.
2. Screw in the adjusting screws until the top of the screw is level with the top of the nut.
3. Tighten the lock nuts.
4. The machine can now be towed with care.
PROCEDURE
1. Slacken the lock nuts each side of the pump.
2. Unscrew in the adjusting screws until they reach their stops.
3. Tighten the lock nuts.
COV00028
1
2
1
2
3
