TA3H, TA3SH & TA3.5SH Page 9 - 9
9. Maintenance
Figure 9.9 - Dipstick MAX and MIN marks.
1. Maximum (MAX) Oil Level
2. Minimum (MIN) Oil Level
(2) To Add Oil.
Oil is added through the filler cap - Figure 9.10 accessible in the engine compartment. Refer to
the Lubrication Tables for the correct grade and quantity of oil.
Figure 9.10. - Engine Oil Filler
PROCEDURE
1. Open the engine cover.
2. Allow oil to settle for a few minutes.
3. Remove the dipstick, wipe clean with paper, check level and replace the dipstick.
4. If the oil level is below the MIN level oil must be added.
COV00033
1
2
1
COV0006
