Page 9 - 22 TA3H, TA3SH & TA3.5SH
9. Maintenance
.
Figure 9.22 - Cover Plate
(b) To Check the Fluid Level
Refer to Figure 9.23
Figure 9.23 - Brake Reservoir
1. Filler Cap
2. Full Mark
PROCEDURE
1. Clean the area around the filler cap.
2. Unscrew the cap and check that the fluid is level with the “Full” mark on the reservoir.
3. Fill as necessary.
4. Replace the filler cap.
5. Clean up any spilt fluid.
1
COV0004
2
1
COV0005
