- Medium-priority alarms XXXX:
▪
0x0001: Baery almost empty – Connect power supply unit
▪
0x0002: CPAP pressure high (adjustable)
▪
0x0004: CPAP pressure low (adjustable)
▪
0x0008: Oxygen concentraon high
▪
0x0010: Oxygen concentraon low
▪
0x0020: Internal temperature too high
- Low-priority alarms XXXX:
▪
0x0001: Fan blocked
▪
0x0004: Leak-Assist
▪
0x0008: Power supply unit disconnected
▪
0x0010: External baery low
▪
0x0020: External baery temperature
- Addional ow set during the push XX.X L/min
▪
Mode X:
▪
C = CPAP
▪
A = Apnea CPAP
▪
N = NIPPV
▪
H = High Flow
Example of live data:
***;2016-04-04;14:09:11;medin-nc3 1004;V1.00;***
07.0;08.7;021;0;0000;0000;0000;03.8;C
07.9;08.7;021;0;0000;0000;0000;03.8;C
07.9;08.7;021;0;0000;0000;0000;03.8;C
07.7;08.7;021;0;0000;0000;0000;03.8;C
07.5;08.7;021;0;0000;0000;0000;03.8;C
06.7;08.7;021;0;0000;0000;0000;03.8;C
3.4.4.2. Trend data
The trend data are divided into two parts: The rst part contains logles of saved alarms and device starts. This
recording contains the data of the last device uses and will connue to be saved even if the medin-NC3® is switched
o. The second part of the trend data is deleted each me the medin-NC3® is switched o. It saves the data since
the last device start, however for a maximum of 28 days. It contains the CPAP pressure, the set ow, the measured
oxygen concentraon, the set addional push ow, the mode, respiratory rate, informaon whether the backup
was acve, the push rate R
insp
, the minimum and maximum possible push rate, the maximum pressure during the
pushes, the set inspiraon me and the set apnea me.
The structure of the trend data is shown below as an example:
###;2016-04-07;14:20:14;medin-nC3 1004;V1.00;alarm record;###
start;2015-04-04;10:59; alarm;04;11:07;0000;0008;0000;for 14:48
alarm;04;1:50 PM;0000;0004;0000;for 12:30 AM
alarm;04;2:14 PM;0002;0002;0000;for 12:36 AM
###;2016-04-07;14:20:15;medin-nc3 1004;V1.00;trend record;###
CPAP; ow;FiO
2
;Finsp;Mode; RR;BU;Rinsp;Pinsp;Tinsp;Tapn;
05.6; 07.0; 021; 00.0; C;018; ; ; ; ; ;
05.6; 07.0; 021; 00.0; C;018; ; ; ; ; ;
05.5; 07.0; 024; 01.0; A;024; -; 000; ; 0.3;10.0;
05.9; 07.5; 024; 01.0; A;018; -; 000; ; 0.3;10.0;
02.5; 06.0; 026; 02.5; N; ; ; ; ; ; ;
04.1; 06.0; 036; 03.7; N; ; ; ; ; ; ;
***;2016-04-07;14:20:51;medin-cnt1004;record complete;###
