- Date: YYYY-MM-DD; (current date, set in the service menu)
- Time: HH:MM:SS; (current me, set in the service menu; switching to
local me or daylight savings me (summer me) must
be performed manually)
- Device name: medin-NC3 ZZZZ (can be set in the service menu)
- SW version: VXXXX (installed main soware version)
- Alarm record; ###
medin Medical Innovaons GmbH
Adam-Geisler-Str. 1
82140 Olching, Germany
+49 8142 448 460
info@medin-medical.com
www.medin-medical.com
IFU_medin-NC3 EN
Rev 05 Status as of 28.04.2021
19 of 68
Start of alarm recording:
Start and alarm recording:
- For each device start, date and me are saved as such:
start; YYYY-MM-DD;HH:MM;
- For each new alarm, day, me, all acve alarms of high, medium and low priority and the duraon
(min:sec) of the alarms are saved:
alarm; DD; HH:MM;HHHH;MMMM;LLLL;for MM:SS
The alarm coding takes place analogously to the coding in the live data (for detailed informaon, see chapter
3.4.4.1). The date is only shown as a day. The month can be determined using the last prior start entry. The alarm
duraon is indicated in minutes and seconds from the start of the alarm unl its end.
Recording the set and measured values:
The trend data contain all values saved in the trend and addional values since the last me the device was switched
on. Every 20 seconds, a line is saved. If a value is not available in the current mode, it is replaced with blank spaces.
The structure is as follows:
- Average value of the CPAP pressure in XX.X mbar
- Set ow in XX.X L/min + if applicable, correcon ow with acvated Leak-Assist
- Measured FiO
2
in XXX%
- Addional set push ow in XX.X L/min
- Current mode: C = CPAP, A = Apnea CPAP, N = NIPPV, H = High Flow, - = Standby
- Measured respiraon rate in XXX / min
- Status of backup (B = acvely running; -= currently not acvely running or generally o)
- Push frequency R
insp
in XXX / min
- Maximum CPAP value during the push in XX.X mbar
- Set push length T
insp
in X.X sec
- Set apnea me in XX.X sec
Please note:
When reading the trend data, there may be me delays upon receipt at the computer or data system. For this
reason, when reading the data, wait unl the last line (
***;2016-0407;14:22:51;medin-nc3® 1004;record complete;) has
been issued. Only then have the trend data been fully received.
