10.001 V * 6.5 Hz/V = 65.0065 Hz
For this example, the displayed Hz in the Transducer Output section of the Transducer
Test Screen should read 65.0091 Hz.
The Accuracy displayed in the Transducer Output section would be equal to the
following,
(65.0065 - 65.0000/ 65.0000) * 100 = % accuracy or
-0.01 %
If this were a 0.02 % transducer, then the firmware would compare the accuracy values
between the Setting Screen and the Test Screen and would display PASS in the
Transducer Output section of the test screen..
-
155
