1.4.2.1.1 Voltage and Current Ranges
1.4.2.1.1.1 Model 8415 (each output module)
Voltage Range Power / Current (Max)
30.00V 150VA @ 5A
150.00V 150VA @ 1A
Current Range (RMS) Power / Voltage (Max)
4.0A 200VA @ 50.0 V
RMS
7.5A 200VA @ 26.7 V
RMS
15.0A 200VA @ 13.4 V
RMS
1.4.2.1.1.2 Model 8430 (each output module)
Voltage Range Power / Current (Max)
30.00V 150VA @ 5.0A
150.00V 150VA @ 1.0A
300.0V 150VA @ 0.5A
Current Range (RMS) Power / Voltage (Max)
4.0A 200VA@ 50.0 V
RMS
7.5A 200VA @ 26.6 V
RMS
15.0A 200VA @ 13.4 V
RMS
30.0A 200VA @ 6.67 V
RMS
1.4.2.1.2 Frequency Ranges
The output module is able to provide a variable frequency output with the following ranges:
DC
00.001 to 99.999
100.01 to 999.99
1.4.2.1.3 Phase Angle
The phase angle may be set from 0° to 359.9° in either lead or lag configuration, clockwise or
counterclockwise rotation. In addition, the user may select the angle display configuration of
±180°. See section 2.2.3.11, Phase Angle Setting, for information regarding Factory Default
settings.
1.5 Timer Control
The Timer can indicate the elapsed time either in seconds or in cycles. The Timer is prearranged
in the setup screens of the respective relay types that are to be evaluated. There are factory
default settings for the timer inputs.
