3.8.5 Voltage Relay Test Menu
This menu permits the setting and testing of a voltage relay. These tests should be conducted in
accordance with the manufacturers relay specifications.
Figure 59 Voltage Relay Test Menu
There are several options to further define the tests to be performed. Selecting one of these
options will present the test setup screen for that option.
The bottom of the screen has common buttons.
File: This selection will take the user to the File
Manager.
Pre-set Test Menu: This selection will return the controller to the
Pre-set Test Menu Screen.
Main Menu: This selection will return the controller to the
Main Menu:
-
