101
Function
code
Name
Description
Value range
Default
value
Change
Bit7: Tuning
Bit8: Overcurrent limited
Bit9: Bus overvoltage limited
Bit10: Torque limited
Bit11: Speed reached (speed mode) /
Speed limited (torque mode)
Bit12: Drive in fault
Bit13: Speed control
Bit14: Torque control
Bit15: Reserved
P01.18
DI1 to DI4 state
0: Invalid
1: Valid
0 to 0x1111
0
*
P01.19
DI5 to DI8 state
0: Invalid
1: Valid
0 to 0x1111
0
*
P01.20
DO state
0: Invalid
1: Valid
0 to 0x1111
0
*
P01.21
AI1 input voltage
Displays the AI1 input voltage.
0.00 to 10.00 V
0
*
P01.22
AI2 input voltage
Displays the AI2 input voltage.
-10.00 to 10.00 V
0
*
P01.23
AI1 input current
Displays the AI1 input current.
0.00 to 20.00 mA
0
*
P01.24
AI2 input current
Displays the AI2 input current.
0.00 to 20.00 mA
0
*
P01.25
AO1 output
0.00 to 100.00%
0.00 to 100.00%
0
*
P01.26
HDI frequency
Displays the HDI frequency.
0.000 to 50.000 kHz
0
*
P01.27
HDO1 frequency
Displays the HDO1 frequency.
0.000 to 50.000 kHz
0
*
P01.28
HDO2 frequency
Displays the HDO2 frequency.
0.000 to 50.000 kHz
0
*
P01.29
PID reference
-100.0% to 100.0%
-100.0% to 100.0%
0
*
P01.30
PID feedback
-100.0% to 100.0%
-100.0% to 100.0%
0
*
