183
Table 7-1 Keypad working mode
Invalid when not in the
panel control mode
The STOP key is valid only in the operating panel control channel.
Stop according to the
defined mode when not
in the panel control
mode
The STOP key is valid in the panel, terminal and serial port operation command
channels.
Press this button, and the drive will stop according to the stop mode defined by
P08.06.
When the STOP/RESET key is used as the fault reset key “RESET”, it is valid only in the local keypad operation command
channel. When you press the “RUN” and “STOP” keys at the same time, the drive will coast to stop.
Hundreds place: Function selection of the M key
When it is set to 0, the M key is disabled.
When it is set to 1, the M key is used as FWD JOG.
When it is set to 2, the M key is used as REV JOG.
When it is set to 3, the M key is used as the direction switchover FWD/REV. In the operating panel operation command
channel, you can switch the direction of output frequency online.
When it is set to 4, the M key is used as the command channel switchover key, only valid during stop. The sequence of
operation command channel switchover:
Operating panel command channel (REM off) → Terminal command channel (REM on) → Serial port command
channel (REM flashing) → Operating panel command channel (REM off).
The operation command channel takes effect immediately once you use the M key for switchover.
Thousands place: Reserved
0: Parameters rewritable
When it is set to 0, all parameters can be changed.
1: Clear fault records
When it is set to 1, fault records related to P97.32–P97.61 will be cleared.
