30
PCBA indicates the power status and whether the state machine enters the OP mode; and the LED on the
communication port indicates whether the communication status of MV810-ECAT01 is normal.
Table 2-6 Description of LED on the PCBA of the expansion box
LED1 status
Description
Action
Flashing
The state machine does
not enter the OP mode
Check whether the ECAT option is properly connected to the host
device
Solid on
The state machine
already entered the OP
mode
No need for actions
LED2 status
Description
Action
Solid on
Normal power supply for
the ECAT option
No need for actions
Off
No power supply for the
ECAT option
Check whether the ECAT option is properly connected to the drive
Table 2-7 Description of LED on the communication port
LED status
Description
Action
Green light flashing
Connected properly, with
data transmission
No need for actions
Green light solid on
Connected properly,
without data
transmission
No need for actions
2.1.3.8 Installation
Accessory list
Accessory list
Specifications
Number
MV810-ECAT01
75 × 60 × 24 mm
1
User manual
A4 × 1
1
For installation, refer to “2.1.1 Installation of accessory cards/options” for details.
