Bus transmission speed
100 Mbps Auto-Defect
Module name
MV810-ECAT02
XML file
MV800_ECAT_CoE_V2.00.xml
SDO
SDO request, SDO response
PDO
Variable PDO mapping
Electrical
specifications
Power voltage
3.3 V DC (provided by the drive)
Insulation voltage
500 V DC
Power consumption
1 W
Weight
25 g
Environment
Noise immunity
ESD (IEC 61800-5-1, IEC 6100-4-2)
EFT (IEC 61800-5-1, IEC 6100-4-4)
Surge Test (IEC 61800-5-1, IEC 6100-4-5)
Conducted Susceptibility Test
(IEC 61800-5-1, IEC 6100-4-6)
Operating/Storage
environment
Operating: -10 to 50℃ (temperature), 90% (humidity)
Storage: -25 to 70℃ (temperature), 95% (humidity)
Vibration/Shock resistance
International standards
GB 4798.3-2007, GB 12668.501—2013/IEC 61800-5-1
(IEC 60068-2-6)
2.1.4.4 Pin definitions
EtherCAT adopts the standard RJ45 ports. This communication option has 2 RJ45 ports: IN and OUT.
The pin definitions of MV810-ECAT02 are listed below:
Pin
Name
Description
1
TX+
Transmit Data+
2
TX-
Transmit Data-
3
RX+
Receive Data+
