49
MV820 models
Main circuit (mm
2
)
Control circuit
(mm
2
)
Recommended pipe-type terminal diameter
ф (mm)
Input cable
Output cable
Control
terminal cable
Input cable
Output
cable
Control
terminal cable
MV820G1-2D0.75B
1.5/1.0
1.5
0.5
2.0/1.7
2.0
1.3
MV820G1-2D1.5B
2.5/1.5
2.5
0.5
2.6/2.0
2.6
1.3
MV820G1-2D2.2B
4/2.5
4.0
0.5
3.2/2.6
3.2
1.3
MV820G1-4T0.4B
1
1
0.5
1.8
1.8
1.3
MV820G1-4T0.75B
1
1
0.5
1.8
1.8
1.3
MV820G1-4T1.5B
1.5
1.5
0.5
2.0
2.0
1.3
MV820G1-2T2.2B
4
4
0.5
3.2
3.2
1.3
MV820G1-4T2.2B
1.5
1.5
0.5
2.0
2.0
1.3
MV820G1-4T4.0B
2.5
2.5
0.5
2.6
2.6
1.3
MV820G1-2T4.0B
6
6
0.5
3.9
3.9
1.3
MV820G1-4T5.5B
4
4
0.5
3.2
3.2
1.3
MV820G1-4T7.5B
6
6
0.5
3.9
3.9
1.3
MV820G1-2T5.5B
6
6
0.5
3.9
3.9
1.3
MV820G1-2T7.5B
6
6
0.5
3.9
3.9
1.3
MV820G1-4T11B
6
6
0.5
3.9
3.9
1.3
MV820G1-4T15B
6
6
0.5
3.9
3.9
1.3
Note: The 2D models include single/three-phase 220 V wiring. The data before and after the slash correspond to the
values of single-phase and three-phase wiring 220 V separately. The parameter values in the table are for
recommendation.
