Mercury 40 Service Manual

2
D
WIRING DIAGRAMS
90-828631R3 MARCH 1999 Page 2D-1
ELECTRICAL
Section 2D - Wiring Diagrams
Table of Contents
Electric Start Wiring Diagram 2D-2. . . . . . . . . . . . . . .
Tiller Handle Wiring Diagram 2D-3. . . . . . . . . . . . . . .
Commander Remote Control (Electric Start) 2D-4. .
Commander 2000 Remote Control
(Electric Start) 2D-5. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Commander 3000 Panel Mount Control 2D-6. . . . . .
Power Trim Switch Wiring Diagram 2D-7. . . . . . . . . .
Remote Wiring Harness Connection
to Engine 2D-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electric Start Remote Control Model 2D-8. . . . . .

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
