IGNITION
Page 2A-22 90-828631R3 MARCH 1999
(CDI) Unit Removal and Installation
1. Remove and install the (CDI) unit as shown.
2. Refer to Section 2 Part D for wiring diagrams.
28341
a
b
a-(CDI) Unit
b-Mounting Bolts (2)
(CDI) Mounting Bolt Torque
100 lb-in. (11.3 Nm)

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
