CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-828631R3 MARCH 1999 Page 5A-9
Adaptor Plate
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 DIPSTICK
2 1 DIPSTICK TUBE
3 1 SEAL
4 1 HEAT SHIELD
5 5 DOWEL PIN
6 1 ELBOW
7 2 STA-STRAP
8 1 TUBING (20 IN.)
9
1 SEAL–driveshaft (NON-BIGFOOT)
9
1 SEAL–driveshaft (BIGFOOT)
10 1 PLUG–oil passage
11 1 GROMMET (NON BIGFOOT)
12 1 ADAPTOR PLATE
13 1 GASKET
14 1 O RING
15 1 PLATE
16 1 HOSE
17 1 BAFFLE
18 2 CLAMP
19 1 BUSHING (NON BIGFOOT)
20 1 GROMMET (POWER TRIM)
21 1 GROMMET (NON-POWER TRIM)
22 8 SCREW (M6x 1 x 20) 130 11
23 3 SCREW (M6 x 1 x 20) 75 8.5
24 1 DEFLECTOR-Oil
25 1 BODY–oil pressure relief 34 46
26 1 COTTER PIN
27 1 PLUNGER
28 1 SPRING
