Mercury 40 Service Manual

CYLINDER BLOCK/CRANKCASE
Page 4B-990-828631R3 MARCH 1999
Powerhead Removal
WARNING
Engine could possibly start when turning flywheel during removal and installation.
To prevent this type of accidental engine starting and possible serious injury,
always remove spark plug leads from spark plugs.
1. Remove the bottom cowls.
2. Open the latch and disengage the vertical shift shaft.
3. Disconnect the power trim harness wires.
53859
c
a
b
a-Open Latch and Disengage Vertical Shift Shaft
b-Power Trim Harness Wires
c-Cut Sta-Strap
4. Disconnect the vent hose.
53726
a
a-Vent Hose

Mercury 40 Specifications

General

Horsepower	40 hp
Starting System	Electric
Steering	Remote
Fuel Induction System	EFI (Electronic Fuel Injection)
Shaft Length	20"
Full Throttle RPM Range	6000
