Mercury 40

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
Page 5A-14 90-828631R3 MARCH 1999
Bottom Cowl Removal
1. Disconnect trim wires.
53860
UP
DN
c
a
b
a-Green/White
b-Lt. Blue/White
c-Red/Purple
2. Remove fuel connector bolt.
a
b
a-Fuel Connector Bolt-M6 x 60
b-Fuel Connector
